RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware
RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware
RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware
RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware
RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware
RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware
RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware
RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware

RAM® Double Ball Mount with Garmin Fishfinder #8-32 Hardware

Part#:
RAM-101-G4
UPC:
793442933172
+ Add to compareAdd to shopping list
  • Features:
  • Drill-down mounting solution; choose either round plate featuring the AMPS hole pattern for attachment to compatible Garmin fishfinder hardware
  • Includes two round ball bases and C size medium length double socket arm; ball and socket technology allows for near-infinite adjustability
  • Made of powder-coated, marine-grade aluminum for durability and reliability in the most demanding environments
  • Backed by a lifetime warranty
Size
Availability and ShippingQuantity
Sizeuniwersalny
Product made to order
Product made to order
Notify about availability
List price$109.65
$121.46
/ pc incl. VAT
Cheap and fast delivery
14 days for easy returns
This product is not available in a stationary store
Safe shopping
  • View details
  • Compatibility
  • Recommended products
  • Ask a question
  • Opinions
The RAM-101-G4 consists of a 6 inch double socket arm, 2.5" diameter round base with the universal AMPS hole pattern and round adapter base that attaches directly to the back of the Garmin echo. Designed into the mount is a 1.5" diameter patented rubber ball and socket system with adjustment points at both socket ends of the arm; this with RAM's rubber ball and socket technology allows for almost infinite adjustment and perfect viewing angles. Included is hardware that is used to attach the Garmin echo to the RAM Mount. See other compatible Garmin devices under "compatibility".
Brand
RAM Mounts
Symbol
RAM-101-G4
Producer code
793442933172
Product Weight
340 g
Hardware Included
(3) #8-32 x 5/8" Machine Screws|(3) #8-32 Nylock Nuts
Product Dimensions
Overall Height: 7.35"
Socket-to-Socket Length
4.66"
Hole Pattern
4-Hole AMPS: 1.181" x 1.496"|3-Hole 120-Degree: 1.812" Diameter
AMPS 4-Hole
3-Hole 120 Degree (Small)
Plate Size
2.5" Diameter
Weight Capacity
Standard Use: 1814.37 gramss|Heavy-Duty Use: 1360.78 gramss
Materials
Marine-grade aluminum
Packaging Type
Retail Bag
Mounting Type
Drill Down
Ball & Socket Size
C Size 1.5" (Holds 1814.37 gramss)
Socket Arm Length
Medium Arm
Device or Accessory Type
Fishfinder
Chartplotter
Vehicle Type
Power Boat
Kayak
Component parts
RAM-201U
RAM-202-G4U
RAM-202U
Socket To Socket Length
4.66"
Ball Size
C Size (1.5")
Garmin ECHOMAP Plus 42cv
Garmin ECHOMAP Plus 43cv
Garmin ECHOMAP Plus 44cv
Garmin ECHOMAP Plus 45cv
Garmin Striker 4
Garmin Striker 4dv
Garmin Striker Plus 4cv
Garmin Striker Vivid 4cv
Garmin echo 100
Garmin echo 150
Garmin echo 300c
Garmin ECHOMAP UHD2 6"
Do you need help? Do you have any questions?Ask a question and we'll respond promptly, publishing the most interesting questions and answers for others.
Ask a question
Ask a question
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.
Write your opinion
Your opinion:
5/5
Add your own product photo:
  • View details
    The RAM-101-G4 consists of a 6 inch double socket arm, 2.5" diameter round base with the universal AMPS hole pattern and round adapter base that attaches directly to the back of the Garmin echo. Designed into the mount is a 1.5" diameter patented rubber ball and socket system with adjustment points at both socket ends of the arm; this with RAM's rubber ball and socket technology allows for almost infinite adjustment and perfect viewing angles. Included is hardware that is used to attach the Garmin echo to the RAM Mount. See other compatible Garmin devices under "compatibility".
    Brand
    RAM Mounts
    Symbol
    RAM-101-G4
    Producer code
    793442933172
    Product Weight
    340 g
    Hardware Included
    (3) #8-32 x 5/8" Machine Screws|(3) #8-32 Nylock Nuts
    Product Dimensions
    Overall Height: 7.35"
    Socket-to-Socket Length
    4.66"
    Hole Pattern
    4-Hole AMPS: 1.181" x 1.496"|3-Hole 120-Degree: 1.812" Diameter
    AMPS 4-Hole
    3-Hole 120 Degree (Small)
    Plate Size
    2.5" Diameter
    Weight Capacity
    Standard Use: 1814.37 gramss|Heavy-Duty Use: 1360.78 gramss
    Materials
    Marine-grade aluminum
    Packaging Type
    Retail Bag
    Mounting Type
    Drill Down
    Ball & Socket Size
    C Size 1.5" (Holds 1814.37 gramss)
    Socket Arm Length
    Medium Arm
    Device or Accessory Type
    Fishfinder
    Chartplotter
    Vehicle Type
    Power Boat
    Kayak
    Component parts
    RAM-201U
    RAM-202-G4U
    RAM-202U
    Socket To Socket Length
    4.66"
    Ball Size
    C Size (1.5")
  • Compatibility
    Garmin ECHOMAP Plus 42cv
    Garmin ECHOMAP Plus 43cv
    Garmin ECHOMAP Plus 44cv
    Garmin ECHOMAP Plus 45cv
    Garmin Striker 4
    Garmin Striker 4dv
    Garmin Striker Plus 4cv
    Garmin Striker Vivid 4cv
    Garmin echo 100
    Garmin echo 150
    Garmin echo 300c
    Garmin ECHOMAP UHD2 6"
