Part#:UPC:
RAM-B-108U-A
793442925115
Brand
Symbol
RAM-B-108U-A
Producer code
793442925115
Product Weight
272 g
Hardware Included
(1) #20 Worm Drive Strap Clamp|(1) #28 Worm Drive Strap Clamp|(1) 6" Rubber Strip
Clamp Range
1" - 2.1" diameter
Socket-to-Socket Length
1.75"
Hole Pattern
4-Hole AMPS: 1.181" x 1.496"|3-Hole 120-Degree: 1.812" Diameter
AMPS 4-Hole
3-Hole 120 Degree (Small)
Weight Capacity
Standard Use: 907.18 gramss|Heavy-Duty Use: 453.59 grams
Materials
Marine-grade aluminum
Packaging Type
Poly Bag
Mounting Type
Handlebar/Rail
Ball & Socket Size
B Size 1" (Holds 907.18 gramss)
Socket Arm Length
Short Arm
Diameter Range
1" - 2.1"
Vehicle Type
ATV
UTV
Component parts
RAM-B-108BU
RAM-B-201U-A
RAM-B-202U
Socket To Socket Length
1.75"
Ball Size
B Size (1")
Ask a question
Write your opinion
- View details
The RAM-B-108U-A consists of a 1" diameter rubber ball connected at a right angle to a v-shaped base, SHORT length double socket arm and 2.5" base that contains the universal AMPS hole pattern. The mount is designed with a RAM 1" diameter patented rubber ball and socket system that has adjustment points at both ends of the double socket arm; this allowing for almost infinite adjustment and perfect viewing angles. BrandSymbolRAM-B-108U-AProducer code793442925115Product Weight272 gHardware Included(1) #20 Worm Drive Strap Clamp|(1) #28 Worm Drive Strap Clamp|(1) 6" Rubber StripClamp Range1" - 2.1" diameterSocket-to-Socket Length1.75"Hole Pattern4-Hole AMPS: 1.181" x 1.496"|3-Hole 120-Degree: 1.812" DiameterAMPS 4-Hole3-Hole 120 Degree (Small)Weight CapacityStandard Use: 907.18 gramss|Heavy-Duty Use: 453.59 gramsMaterialsMarine-grade aluminumPackaging TypePoly BagMounting TypeHandlebar/RailBall & Socket SizeB Size 1" (Holds 907.18 gramss)Socket Arm LengthShort ArmDiameter Range1" - 2.1"Vehicle TypeATVUTVComponent partsRAM-B-108BURAM-B-201U-ARAM-B-202USocket To Socket Length1.75"Ball SizeB Size (1") - Recommended products
