RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium
RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium
RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium
RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium
RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium
RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium
RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium
RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium

RAM® Motorcycle Brake/Clutch Reservoir Mount with Diamond Plate - Medium

Part#:
RAM-B-174U
UPC:
793442901812
+ Add to compareAdd to shopping list
Size
Availability and ShippingQuantity
Sizeuniwersalny
Product made to order
Product made to order
Notify about availability
List price$82.23
$94.05
/ pc incl. VAT
Cheap and fast delivery
14 days for easy returns
This product is not available in a stationary store
Safe shopping
  • View details
  • Recommended products
  • Ask a question
  • Opinions
The RAM-B-174U consists of a 1" diameter rubber ball, double socket arm, hardware for mounting to both brake/clutch reservoirs and rails that are 0.5" to 1.25" in diameter. The mounting hardware for brake/clutch reservoirs include both standard and metric mounting bolts. Designed into the mount is a 1" diameter patented rubber ball and socket system with adjustment points at both ends of the socket arm; this with a twist of the arm knob allows you to move the mount to your optimum viewing position.
Brand
RAM Mounts
Symbol
RAM-B-174U
Producer code
793442901812
Product Weight
376 g
Hardware Included
(2) M6 x 55mm Hex Bolts|(2) #1/4-20 x 2" Hex Bolts|(2) 1/4"-20 x 2.5" Hex Bolts|(2) 1/2" Spacers|(2) 1/4" Split Lock Washers|(1) 1/4"-20 U-Bolt for .5" - 1" Rails|(1) 1/4"-20 U-Bolt for 1" - 1.25" Rails|(2) 1/4"-20 Nylock Nuts|(2) Rubber Caps|(1) U-Bolt S
Clamp Range
.5" - 1.25" diameter
Socket-to-Socket Length
3"
Hole Pattern
2-Hole AMPS: 1.912"
AMPS 2-Hole
Weight Capacity
Standard Use: 907.18 gramss|Heavy-Duty Use: 453.59 grams
Materials
Marine-grade aluminum
Packaging Type
Poly Bag
Mounting Type
Handlebar/Rail
Brake/Clutch Reservoir
Ball & Socket Size
B Size 1" (Holds 907.18 gramss)
Socket Arm Length
Medium Arm
Diameter Range
.5" - 1.25"
Vehicle Type
Motorcycle
Component parts
RAM-B-201U
RAM-B-238U
RAM-B-309-7U
Socket To Socket Length
3"
Ball Size
B Size (1")
Do you need help? Do you have any questions?Ask a question and we'll respond promptly, publishing the most interesting questions and answers for others.
Ask a question
Ask a question
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.
Write your opinion
Your opinion:
5/5
Add your own product photo:
  • View details
    The RAM-B-174U consists of a 1" diameter rubber ball, double socket arm, hardware for mounting to both brake/clutch reservoirs and rails that are 0.5" to 1.25" in diameter. The mounting hardware for brake/clutch reservoirs include both standard and metric mounting bolts. Designed into the mount is a 1" diameter patented rubber ball and socket system with adjustment points at both ends of the socket arm; this with a twist of the arm knob allows you to move the mount to your optimum viewing position.
    Brand
    RAM Mounts
    Symbol
    RAM-B-174U
    Producer code
    793442901812
    Product Weight
    376 g
    Hardware Included
    (2) M6 x 55mm Hex Bolts|(2) #1/4-20 x 2" Hex Bolts|(2) 1/4"-20 x 2.5" Hex Bolts|(2) 1/2" Spacers|(2) 1/4" Split Lock Washers|(1) 1/4"-20 U-Bolt for .5" - 1" Rails|(1) 1/4"-20 U-Bolt for 1" - 1.25" Rails|(2) 1/4"-20 Nylock Nuts|(2) Rubber Caps|(1) U-Bolt S
    Clamp Range
    .5" - 1.25" diameter
    Socket-to-Socket Length
    3"
    Hole Pattern
    2-Hole AMPS: 1.912"
    AMPS 2-Hole
    Weight Capacity
    Standard Use: 907.18 gramss|Heavy-Duty Use: 453.59 grams
    Materials
    Marine-grade aluminum
    Packaging Type
    Poly Bag
    Mounting Type
    Handlebar/Rail
    Brake/Clutch Reservoir
    Ball & Socket Size
    B Size 1" (Holds 907.18 gramss)
    Socket Arm Length
    Medium Arm
    Diameter Range
    .5" - 1.25"
    Vehicle Type
    Motorcycle
    Component parts
    RAM-B-201U
    RAM-B-238U
    RAM-B-309-7U
    Socket To Socket Length
    3"
    Ball Size
    B Size (1")
